Certificates Approved Polymer Li Ion Battery 502530 3.7V 300mah Lipo Battery 4.2V
| Name | Lithium Ion Polymer Battery |
| Model Number | AUK502530 |
| Voltage | 3.7V |
| Capacity | 370mAh |
| Dimension | 5.0(T)*25(W)*30(L) mm |
| Standard Charge Current | 0.2C/0.5C |
| Maxium Charge Current | 1C |
| Working Voltage | 3.0~4.2V |
| Cut Off Voltage | 4.2V |
| Cycle Life | 500-1000 Times |
| Temperature | Charging: |
| Storage Humidity | Charging: 0°C~40°C
Discharging:-10°C~45°C
Storage: ≤1 month -10°C ~ 40°C
≤6 months 0°C ~ 35 °C |
| Appearance | Without scratch, distortion, contamination and leakage |
| Standard Environmental Condition | Temperature: 23±5°C
Humidity: 45-75%RH
Atmospheric Pressure: 86-106 Kpa |
| PCB | Yes |
| Wire | Yes |
| Package | Blue PVC |
| Certificate | CE, RoHS |
1. Before using this product, be sure to read the product manual in detail, and operate correctly according to the instructions in the manual.
2. Do not disassemble the device by yourself. This product is not equipped with any parts that can be disassembled/repaired by yourself.
3. It is strictly forbidden to make the product object or heat source contact. It is strictly forbidden to throw this product into fire or water, and it is strictly forbidden to charge the mobile power in an environment below 0°C.
4. Do not vibrate, knock or impact this product violently. If the product encounters strong impact, strong extrusion, or falls from a high place, causing the shell to deform or bulge, please stop using the product.
5. Do not expose this product to sunlight, do not place this product in an environment with corrosive substances, and do not use other chemical solutions to clean this product.
6. If the product is abnormally hot or leaks, please stop using it immediately. If the liquid accidentally splashes into the eyes, do not rub the eyes, rinse the eyes with clean water immediately, and seek medical attention immediately if it is serious.
7. In order to avoid abnormality of this product, it is recommended to use the charging cable, adapter and power supply device produced by the original factory.
8. Please dispose of waste mobile power according to national environmental protection regulations
9. Please keep this product out of the reach of children.
Payment Terms | 100%T/T in adance, Bank remittance. Paypal ,others |
MOQ | Please contact us |
Supply ability | 150000 pieces/per week |
Cycle Life | 800 times+ |
Business Type | Manufacturer |
Quality | "Grade A cells" |
Rechargable | Yes |
Applicant | Consumer Electronics |
AUK Other Hot Selling Lithium Polymer Battery Model for your Choose
Other lithium polymer battery model as below:
| Model | Dimension | With PCM Dimension | Capacity |
| 302025 | 3.0*20*25mm | 3.2*21*27.5mm | 3.7V 100mAh |
| 302530 | 3.0*25*30mm | 3.2*26*32.5mm | 3.7V 180mAh |
| 401824 | 4.0*18*24mm | 4.2*19*26.5mm | 3.7V 180mAh |
| 402525 | 4.0*25*25mm | 4.2*26*27.5mm | 3.7V 200mAh |
| 483450 | 4.8*34*50mm | 5.0*35*52.5mm | 3.7V 850mAh |
| 502030 | 5.0*20*30mm | 5.2*21*32.5mm | 3.7V 240mAh |
| 502525 | 5.0*25*25mm | 5.2*26*27.5mm | 3.7V 180mAh |
| 503030 | 5.0*30*30mm | 5.2*31*32.5mm | 3.7V 430mAh |
| 523450 | 5.2*34*50mm | 5.4*35*52.5mm | 3.7V 1000mAh |
| 553444 | 5.5*34*44mm | 5.7*35*46.5mm | 3.7V 850mAh |
| 553640 | 5.5*36*40mm | 5.7*37*42.5mm | 3.7V 850mAh |
| 553759 | 5.5*37*59mm | 5.7*38*61.5mm | 3.7V 1400mAh |
| 602030 | 6.0*20*30mm | 6.2*21*32.5mm | 3.7V 300mAh |
| 602240 | 6.0*22*40mm | 6.2*23*42.5mm | 3.7V 500mAh |
| 602535 | 6.0*25*35mm | 6.2*26*37.5mm | 3.7V 500mAh |
| 602663 | 6.0*26*63mm | 6.2*27*65.5mm | 3.7V 1000mAh |
| 603030 | 6.0*30*30mm | 6.2*31*32.5mm | 3.7V 520mAh |
| 603040 | 6.0*30*40mm | 6.2*31*42.5mm | 3.7V 750mAh |
| 603048 | 6.0*30*48mm | 6.2*31*50.5mm | 3.7V 900mAh |
| 603450 | 6.0*34*50mm | 6.2*35*52.5mm | 3.7v 1050mAh |
| 702040 | 7.0*21*40mm | 7.2*22*42.5mm | 3.7V 500mAh |
| 753048 | 7.5*30*48mm | 7.7*31*50.5mm | 3.7V 1200mAh |
| 803035 | 8.0*30*35mm | 8.2*31*37.5mm | 3.7V 800mAh |
